Portable Overhead Hoist

Common Types of Portable Cranes

• Portable Gantry Crane: A mobile, A-frame crane mounted on wheels, ideal for lifting and transporting loads over short distances within confined areas.

• Mini Jib Crane: A space-saving jib crane with a sturdy base, commonly utilized for workbenches or in tight, confined spaces where overhead lifting is required.

• Folding Portable Crane: A collapsible crane that offers easy storage and portability, typically used for maintenance tasks or quick installations in varied locations.

• Adjustable Height Gantry: This gantry crane features a customizable height, allowing it to be adapted for different workspace requirements, including moving through doors or beneath obstacles.

Main Components

• Mobile Base Frame: Equipped with a mobility system, featuring casters or wheels for easy movement and repositioning.

• Vertical Support Columns: Telescoping or fixed columns providing vertical support for the entire crane structure.

• Cross Beam: The main horizontal beam, available in profile or box girder design, supporting the lifting mechanism.

• Lifting Hoist: The hoist mechanism, available in chain or wire rope options, designed for vertical load lifting.

• Electrical System: Powered by a flat cable or drag chain, ensuring stable energy transmission for smooth operation.

• Control System: Operated via pendant control or an optional wireless remote, providing ease of use and precision handling.

Technical Specifications

Key Features

• Modular Design for Easy Setup: Built for fast assembly and relocation, offering flexibility in deployment.

• Enhanced Mobility: Equipped with lockable wheels or caster systems for smooth movement and secure positioning.

• Versatile for Any Environment: Suitable for use in both indoor and outdoor settings, providing flexibility in various locations.

• Compatible with Hoisting Systems: Works seamlessly with both chain and wire rope hoists, offering versatility in lifting operations.

• Tailored Configurations: We can customize the height, span, and load capacity to meet specific operational requirements.

• Low Maintenance & Simple Operation: Designed for minimal upkeep, ensuring hassle-free use and long-term reliability.

• Perfect for Space-Constrained or Temporary Workstations: Ideal for environments with limited space or when a temporary solution is needed.

Typical Applications

• Production Lines and Compact Workspaces: Ideal for assembly lines and small-scale workshops, providing efficient lifting solutions.

• Maintenance & Repair Facilities: Perfect for use in maintenance stations, ensuring smooth and safe lifting operations.

• Outdoor Equipment Handling: Versatile for outdoor environments, offering reliable lifting solutions for various equipment.

• Automotive Parts Lifting: Great for lifting vehicle components in automotive workshops or assembly areas.

• Temporary Storage Setups: Efficient for temporary warehouse configurations, ensuring safe handling of goods.

• Mobile Installation Teams: Convenient for use by mobile teams during installations, providing portability and ease of use.

Crane Types Comparison Table
