Our overhead hoist I beam is designed to offer superior strength and reliability in lifting operations. With a range of customizable sizes and configurations, these beams are engineered to support the efficient operation of hoists, ensuring smooth movement of heavy loads in manufacturing, construction, and warehouse environments.
Whether you need to build a new lifting system or upgrade an existing one, the overhead hoist I beam provides a flexible and durable solution that adapts to various applications. Made with high-strength steel or aluminum, our I beams deliver both long-lasting performance and easy maintenance. These beams can be easily integrated with electric or manual hoists to create an efficient lifting system tailored to your specific needs.
Electric Chain Hoist: The main lifting component powered by an electric motor that drives the lifting chain for vertical motion.
Load Chain: A high-strength alloy chain used for lifting, offering smooth, controlled, and reliable load handling.
Trolley: The unit that transports the hoist along the crane’s girder. Available in both single and double girder configurations.
Girder: The primary horizontal beam, either a profile or box girder, that provides support for the trolley and hoist.
Hooks: Heavy-duty forged steel hooks, designed to meet industrial safety standards for secure load handling.
Control System: Operates via pendant control with a festoon system or an optional wireless remote for convenient operation.
Travel Motor & Drive: The motor and drive system ensure a smooth, precise, and continuous horizontal motion of the crane.
Power Supply System: The drag chain or cable system delivers a stable and reliable power source to the hoist, ensuring continuous operation.
Load Capacity: Capable of lifting loads up to 30 tons
Hoisting Height (HOL): Reaches up to 12 meters
Hoisting Speed: Ranges from 0.6 to 7 m/min, depending on the configuration
Operating Temperature: Designed to function within a temperature range of -10°C to +40°C
Suitable Environment: Ideal for indoor applications
Number of Hoists: One hoist per crane
Crane Configuration: Available in both single girder and double girder options
Girder Type: Profile girder for spans up to 12 meters; box girder for spans up to 30 meters
Travel Motion: Smooth, stepless frequency control for precise movement
Lifting Control: Available in single speed, dual speed, or stepless variable frequency
Power Supply to Hoist: Powered by either flat cable or drag chain
Rated Voltage: Compatible with 380–415V/50Hz or 440–480V/60Hz
Control Type: Pendant control (festoon system), with an optional wireless remote for convenience
Compact and Lightweight: Easy to install and relocate, ideal for low headroom spaces
Cost-Effective: Lower initial investment and maintenance costs
Precise Load Control: Accurate vertical lifting and positioning
Low Noise and Vibration: Smooth, quiet operation for indoor environments
Simple Installation: Suitable for small-scale cranes, monorails, or ceiling systems
| Feature | Electric Chain Hoist Crane | Wire Rope Hoist Crane | Jib Crane | Workstation Crane |
|---|---|---|---|---|
| Lifting Capacity | Light to Medium (up to 5 tons) | Medium to Heavy (up to 80 tons) | Light (up to 2 tons) | Light (up to 2 tons) |
| Lifting Medium | Alloy Chain | Wire Rope (synthetic/steel) | Chain or manual | Chain |
| Lifting Speed | Moderate | Fast | Moderate | Moderate |
| Precision | High | Medium | Medium | High |
| Durability | Medium | High | Medium | Medium |
| Installation | Simple | Complex | Wall/Floor Mounted | Modular Overhead Track |
| Best Use Case | Workshops, maintenance, small factories | Industrial plants, long cycles | Workstations, localized lifting | Repetitive small item handling |
| Cost | Lower | Higher | Medium | Medium |
Compact manufacturing units: Ideal for small-scale production and flexible manufacturing setups with limited space.
Maintenance and repair workshops: Suitable for facilities that require heavy-duty lifting for maintenance and repairs of machinery and equipment.
Production lines and assembly zones: Perfect for high-efficiency, repetitive tasks in manufacturing and assembly processes.
Storage and distribution facilities: Designed to handle heavy loads efficiently for warehouses, distribution centers, and logistics operations.
Automobile and components manufacturing plants: Essential for lifting and transporting heavy parts and assemblies in the automotive production process.
Light construction and prefabrication workshops: Effective for assembling components and structures in construction sites, ensuring smooth material handling and movement.
