Overhead Gantry

Main Components

• The Wire Rope Hoist serves as the primary lifting mechanism, utilizing a drum to wind and unwind the wire rope, enabling vertical movement.

• The Lifting Rope consists of a standard synthetic rope, with the option of using high-strength steel wire ropes for more demanding, heavy-duty applications.

• The Trolley supports the hoist and moves along the crane’s girder, available in either a single or double girder configuration.

• The Main Girder acts as the horizontal supporting beam for both the trolley and hoist. It can be designed as either a profile girder or a box girder, depending on specific needs.

• End Carriages contain the wheels that allow the crane to traverse along the rails or ground surface.

• Hooks are crafted in accordance with the DIN 15401 standard, ensuring secure and safe lifting.

• The Control System is operated through pendant control, remote control, or advanced integrated smart features, allowing precise management of crane functions.

• The Electrical System powers the crane’s operations, incorporating motors, wiring, and optional intelligent functions, such as hook centering and obstacle detection.

Technical Specifications

• Load Capacity: Capable of lifting up to 50 tons.

• Lifting Height: Can handle lifting heights of up to 24 meters.

• Span: Maximum span capacity of 30 meters.

• Crane Configuration: Available in Single Girder or Double Girder designs.

• Girder Style: Choose between Profile Girder or Box Girder based on your needs.

• Lifting Rope: Standard synthetic rope, with the option for steel wire rope for heavy-duty applications.

• Hoisting Motor: Includes 2-speed hoisting (standard) or variable frequency drive (optional) for enhanced control.

• Temperature Range: Operates effectively in temperatures ranging from +5°C to +40°C.

• Coating: 70 µm epoxy resin powder coating with an anodized aluminum frame for added durability and corrosion resistance.

• Hooks: Manufactured according to DIN 15401 safety standards for secure lifting.

• Trolley Compatibility: Suitable for both single girder and double girder crane configurations.

• Power Supply: Options for flat cable or drag chain systems for energy delivery.

• Control Options: Available with pendant control, wireless remote control, or operator cabin based on user preference.

• Smart Features: Includes advanced functions like hook centering, obstacle prevention, and auto-follow for improved safety and efficiency.

• Environment: Designed for both indoor and outdoor use, offering versatile installation options.

Key Advantages

• High Lifting Capacity: Typically from 1 ton up to dozens of tons, or even higher for special applications

• Suitable for Complex Working Conditions: Performs reliably under high-frequency and high-intensity operations

• Long Service Life: Steel wire rope offers excellent wear resistance, ideal for long-term continuous use

• Fast Lifting Speed: Ensures higher efficiency, especially beneficial for long lifting strokes

• Highly Customizable: Flexible design options to suit different rail systems and working environments

Comparison with Other Cranes

Application Industry

• Steel and metal processing facilities

• Equipment manufacturing workshops

• Heavy machinery assembly lines

• Infrastructure and construction projects

• Warehouses and logistics hubs

• Power plants and mining operations
