The Mobile Bridge Crane is a dynamic and versatile lifting solution designed for businesses that require flexibility and high performance. This crane combines the reliability of a traditional bridge crane with the added mobility to move across your workspace, offering excellent material handling capabilities in environments with changing requirements.
With a robust design, the Mobile Bridge Crane is capable of handling heavy loads efficiently, making it perfect for industries that need to move materials quickly and safely. It can be customized for different spans, heights, and lifting capacities, ensuring it fits your specific lifting needs.
Electric Chain Hoist: The primary lifting mechanism powered by an electric motor that drives the chain for vertical movement.
Load Chain: A durable, high-strength alloy chain used to safely lift and lower loads, offering smooth and controlled operation.
Trolley: A component that holds the hoist and moves horizontally along the girder, available in both single and double girder configurations.
Girder: The main horizontal beam that provides support for the hoist and trolley, available in profile or box girder designs.
Hooks: Strong forged steel hooks that meet industry safety standards, designed for secure load lifting.
Control System: Options for pendant control (festoon system) or a wireless remote control for convenient crane operation.
Travel Motor & Drive: A motorized drive system with stepless travel control, ensuring smooth, accurate horizontal movement.
Power Supply System: A drag chain or cable system that ensures a stable energy flow to the hoist for reliable operation.
Load Capacity: Capable of lifting up to 30 tons.
Hoisting Height (HOL): Maximum lifting height of 12 meters.
Hoisting Speed: Adjustable from 0.6 to 7 m/min, depending on the specific configuration.
Operating Temperature: Designed for use in temperatures ranging from -10°C to +40°C.
Suitable Environment: Ideal for indoor operations.
Number of Hoists: Each crane is equipped with a single hoist.
Crane Configuration: Available in both single and double girder designs.
Girder Type: Choose between profile girders (for spans up to 12m) or box girders (for spans up to 30m).
Travel Motion: Smooth and precise motion controlled by stepless frequency adjustment.
Lifting Control: Options include single-speed, dual-speed, or stepless variable frequency control.
Power Supply to Hoist: Powered by either a flat cable or drag chain system.
Rated Voltage: Operates on 380–415V / 50Hz or 440–480V / 60Hz.
Control Type: Includes pendant control (festoon system), with the option for wireless remote control.
Compact and Lightweight: Easy to install and relocate, ideal for low headroom spaces
Cost-Effective: Lower initial investment and maintenance costs
Precise Load Control: Accurate vertical lifting and positioning
Low Noise and Vibration: Smooth, quiet operation for indoor environments
Simple Installation: Suitable for small-scale cranes, monorails, or ceiling systems
| Feature | Electric Chain Hoist Crane | Wire Rope Hoist Crane | Jib Crane | Workstation Crane |
|---|---|---|---|---|
| Lifting Capacity | Light to Medium (up to 5 tons) | Medium to Heavy (up to 80 tons) | Light (up to 2 tons) | Light (up to 2 tons) |
| Lifting Medium | Alloy Chain | Wire Rope (synthetic/steel) | Chain or manual | Chain |
| Lifting Speed | Moderate | Fast | Moderate | Moderate |
| Precision | High | Medium | Medium | High |
| Durability | Medium | High | Medium | Medium |
| Installation | Simple | Complex | Wall/Floor Mounted | Modular Overhead Track |
| Best Use Case | Workshops, maintenance, small factories | Industrial plants, long cycles | Workstations, localized lifting | Repetitive small item handling |
| Cost | Lower | Higher | Medium | Medium |
Compact Manufacturing Facilities: Ideal for small-scale production and assembly tasks, where space optimization and efficient workflow are key.
Repair and Maintenance Stations: Designed for environments where heavy equipment and machinery require frequent service, offering reliable lifting and material handling solutions.
Production Lines and Assembly Zones: Perfect for high-efficiency work environments where assembly tasks require precise and smooth lifting operations.
Storage and Distribution Hubs: Optimized for warehouses and logistics centers, ensuring safe handling and quick movement of goods across the facility.
Automotive and Component Manufacturing Plants: Ideal for automotive assembly lines and parts factories, providing reliable and heavy-duty lifting solutions for large components.
Light Construction and Prefabrication Areas: Suitable for construction sites and prefabrication facilities, supporting the assembly and handling of lightweight materials and components.
