The jib gantry crane is a robust and flexible lifting solution, designed to handle heavy loads with ease and efficiency. It combines the best features of jib cranes and gantry cranes, providing unmatched versatility for applications in industries such as manufacturing, construction, and logistics. With its sturdy structure and efficient lifting mechanism, the jib gantry crane ensures maximum performance, even in challenging environments.
This crane features a gantry-style base for mobility and stability, allowing it to easily move along tracks or across open areas while lifting materials with precision. The jib arm offers horizontal reach and can be adjusted for different lifting heights, making it ideal for working in confined spaces or for specialized tasks.
A jib gantry crane is made up of several key structural and mechanical components:
Main Girder: The horizontal beam that supports the hoist trolley, available in either a single or double girder design.
Supporting Legs: Vertical columns that uphold the main girder and connect to the ground rails or wheels for stability.
End Carriages / Wheels: Positioned at the base of the legs, enabling the crane to move along the rails or across the ground surface.
Hoisting Trolley: Travels along the girder and carries the hoist for lifting and lowering heavy loads.
Hoist: Can be either a wire rope or chain hoist, responsible for the lifting function.
Electrical System: Supplies power to all crane functions, including motors, control panels, and necessary cabling.
Control Options: Provides various operation modes such as pendant control, wireless remote control, or an operator cabin, depending on user requirements.
| Item | Specifications |
| Lifting Capacity | ≤ 200 tons |
| Lifting Height | ≤ 36 meters |
| Span | ≤ 50 meters |
| Crane Options | Single Girder / Double Girder |
| Girder Design | Profile or Box Girder |
| Rope Options | Synthetic Rope (Standard) / Wire Rope (Optional) |
| Hoisting Motor | 2-Speed Hoisting (Standard) / Variable Frequency Drive (Optional) |
| Temperature Range | +5°C to +40°C (Standard) |
| Paint Coating | 70 µm Epoxy Powder Coating with Anodized Aluminum Frame |
| Hooks Standard | DIN 15401 |
| Trolley Type | Single Girder or Double Girder Crane |
| Power Supply | Drag Chain or Flat Cable |
| Control Options | Pendant Control / Remote Control / Operator Cabin |
| Integrated Smart Features | Hook Centering, Obstacle Prevention, Auto-Follow |
| Environment | Indoor & Outdoor |
Impressive Lifting Capacity: Capable of lifting heavy loads up to 200 tons.
Ideal for Outdoor Use: Perfect for locations without an existing overhead structure.
Tailored Design: Customizable to fit various spans, heights, and rail types.
Affordable Setup: No need for the installation of additional support beams.
Flexible Control Systems: Offers manual, remote, and operator cabin control options.
Enhanced Efficiency: Quick lifting speeds and intelligent features boost overall productivity.
| Feature | Gantry Crane | Overhead Crane | Jib Crane |
|---|---|---|---|
| Support Type | Freestanding legs on ground | Supported by building structure | Mounted to wall or column |
| Installation | Easy, no building structure required | Requires runway beams | Fixed position |
| Span | Up to 50 meters | Up to 30 meters | Limited |
| Load Capacity | Very high (up to 200 tons) | High | Low to moderate |
| Mobility | Excellent (rail or tire mounted) | Fixed to runway beams | Limited swivel range |
| Outdoor Use | Ideal | Limited | Rare |
Shipbuilding and Repair Yards
Steel Fabrication Plants
Container Loading/Unloading at Ports
Precast Concrete Assembly Yards
Large Equipment Assembly Areas
Heavy Industrial Warehouses
