Main Components

• Wire Rope Hoist: Core lifting unit using a drum to wind or unwind the wire rope, enabling vertical load movement.

• Lifting Rope: Standard synthetic rope with the option to use high-strength steel wire rope for heavy-duty lifting tasks.

• Trolley: Supports the hoist and travels horizontally along the crane’s girder; compatible with both single-girder and double-girder configurations.

• Main Girder: The primary horizontal beam that carries the trolley and hoist, available in profile or box girder designs.

• End Carriages: Contain wheels that allow the crane to move smoothly along the rails.

• Hooks: Manufactured according to DIN 15401 standards for safe and reliable lifting.

• Control System: Operable through pendant control, wireless remote, or integrated intelligent control features.

• Electrical System: Comprises motors, wiring, and optional smart functionalities such as hook centering and obstacle prevention.

Technical Specifications

• Capacity: The crane can lift loads of up to 50 tons, providing reliable heavy-duty performance.

• Height: Offers a maximum lifting height of 24 meters, suitable for tall industrial spaces.

• Span: Supports a span of up to 30 meters, adaptable to various workshop layouts.

• Crane Type: Available in Single Girder or Double Girder configurations to match operational needs.

• Girder Design: Choose between Profile Girder (up to 12m span) or Box Girder (up to 30m span) depending on application.

• Lifting Rope: Standard synthetic rope with optional steel wire rope for heavy-duty lifting.

• Hoisting Motor: 2-speed standard with an optional variable frequency for precise control.

• Operating Temperature: Functions reliably in temperatures from +5°C to +40°C.

• Paint Coating: Finished with 70 µm epoxy resin powder on anodized aluminum for enhanced durability.

• Hook Standard: DIN 15401 compliant forged hook for safe lifting.

• Trolley Type: Compatible with both single and double girder systems.

• Power Supply: Energy delivered via flat cable or drag chain for stable operation.

• Control Options: Operable by pendant control or optional wireless remote control.

• Smart Features: Includes hook centering, obstacle prevention, and auto-follow function for safer, smarter operation.

• Environment: Suitable for both indoor and outdoor applications, offering flexibility across industries.

Key Advantages

• High Lifting Capacity: Typically from 1 ton up to dozens of tons, or even higher for special applications

• Suitable for Complex Working Conditions: Performs reliably under high-frequency and high-intensity operations

• Long Service Life: Steel wire rope offers excellent wear resistance, ideal for long-term continuous use

• Fast Lifting Speed: Ensures higher efficiency, especially beneficial for long lifting strokes

• Highly Customizable: Flexible design options to suit different rail systems and working environments

Comparison with Other Cranes

Application Industry

Wire rope hoist cranes are widely used across various industries that require safe and efficient handling of heavy loads. Common application areas include:

• Steel and metal processing plants

• Equipment manufacturing workshops

• Heavy machinery assembly lines

• Infrastructure and construction projects

• Warehousing and logistics centers

• Power plants and mining operations

With flexible configuration options and intelligent features, the wire rope hoist crane system is an ideal solution for projects that demand performance, reliability, and safety.
