If you’re searching for an affordable yet robust lifting solution, our gantry cranes provide the perfect balance of performance, reliability, and cost-efficiency. At Yonghao Crane Co., we offer a diverse range of gantry cranes designed to handle heavy-duty lifting tasks with ease. Whether you’re in need of a mobile, semi-mobile, or fixed gantry crane, we ensure that our products meet the highest quality standards at competitive prices. Our gantry cranes are ideal for operations where overhead space is limited, and they offer flexible configurations to suit various applications across industries.
Main Girder: The primary horizontal beam that supports the hoisting trolley. It can be designed with either a single girder or double girder, depending on the load and application requirements.
Supporting Legs: Vertical columns that provide support to the main girder and connect to the ground rails or wheels, allowing the crane to travel across the workspace.
End Carriages / Wheels: Positioned at the bottom of the supporting legs, these enable the crane to move smoothly along the rails or ground surface, ensuring stable operation during horizontal travel.
Hoisting Trolley: The moving component that travels along the main girder and carries the hoist, used for lifting and lowering heavy loads.
Hoist: The lifting unit, which can either be a wire rope or chain hoist, designed to raise and lower loads efficiently.
Electrical System: Provides power for all crane movements, including the control panels, motors, and cabling that ensure smooth operation of the crane.
Control Options: Available in pendant control, wireless remote control, or operator cabin configurations, offering flexibility to suit the specific operational needs of the user.
| Item | Specifications |
| Lifting Capacity | ≤ 200 tons |
| Lifting Height | ≤ 36 meters |
| Span | ≤ 50 meters |
| Crane Options | Single Girder / Double Girder |
| Girder Design | Profile or Box Girder |
| Rope Options | Synthetic Rope (Standard) / Wire Rope (Optional) |
| Hoisting Motor | 2-Speed Hoisting (Standard) / Variable Frequency Drive (Optional) |
| Temperature Range | +5°C to +40°C (Standard) |
| Paint Coating | 70 µm Epoxy Powder Coating with Anodized Aluminum Frame |
| Hooks Standard | DIN 15401 |
| Trolley Type | Single Girder or Double Girder Crane |
| Power Supply | Drag Chain or Flat Cable |
| Control Options | Pendant Control / Remote Control / Operator Cabin |
| Integrated Smart Features | Hook Centering, Obstacle Prevention, Auto-Follow |
| Environment | Indoor & Outdoor |
Impressive Load Capacity: Capable of lifting heavy weights up to 200 tons.
Ideal for Outdoor Use: Well-suited for environments where there is no existing overhead structure.
Flexible Configuration: Can be tailored to various spans, heights, and rail types to meet specific project needs.
Affordable Installation: Eliminates the need for constructing additional support beams, making it a cost-efficient solution.
Multiple Control Options: Offers a variety of control modes including manual, remote, or operator cabin, depending on user preferences.
Enhanced Efficiency: Delivers fast lifting speeds and incorporates advanced features for smoother operation and improved productivity.
| Feature | Gantry Crane | Overhead Crane | Jib Crane |
|---|---|---|---|
| Support Type | Freestanding legs on ground | Supported by building structure | Mounted to wall or column |
| Installation | Easy, no building structure required | Requires runway beams | Fixed position |
| Span | Up to 50 meters | Up to 30 meters | Limited |
| Load Capacity | Very high (up to 200 tons) | High | Low to moderate |
| Mobility | Excellent (rail or tire mounted) | Fixed to runway beams | Limited swivel range |
| Outdoor Use | Ideal | Limited | Rare |
Shipbuilding and Repair Yards
Steel Fabrication Plants
Container Loading/Unloading at Ports
Precast Concrete Assembly Yards
Large Equipment Assembly Areas
Heavy Industrial Warehouses
