30 Ton Gantry Crane

Main Components

• Wire Rope Hoist: The central lifting unit that uses a drum to wind and unwind the wire rope for vertical movement.

• Lifting Rope: Standard synthetic rope with optional high-strength steel wire rope for heavy-duty lifting.

• Trolley: Carries the hoist and moves horizontally along the crane’s girder (available in single or double girder form).

• Main Girder: The horizontal beam that supports the trolley and hoist; available in profile or box girder designs.

• End Carriages: House the wheels that allow the crane to travel along the rails.

• Hooks: Made according to DIN 15401 standard for secure lifting.

• Control System: Operated via pendant control, remote control, or integrated smart features.

• Electrical System: Includes motors, wiring, and optional smart functions like hook centering and obstacle prevention.

Technical Specifications

• Capacity: Supports loads up to 50 tons.

• Height: Maximum lifting height reaches 24 meters.

• Span: Covers spans of up to 30 meters.

• Crane Type: Available in Single Girder or Double Girder configurations.

• Girder Design: Options include Profile Girder or Box Girder.

• Lifting Rope: Standard synthetic rope; high-strength steel wire rope optional for heavy-duty lifting.

• Hoisting Motor: 2-speed motor standard; variable frequency drive optional for flexible operation.

• Operating Temperature: Suitable for environments between +5°C and +40°C.

• Paint Coating: 70 µm epoxy resin powder coating with anodized aluminum frame for durability.

• Hook Standard: Compliant with DIN 15401 for safe lifting.

• Trolley Type: Compatible with both single and double girder cranes.

• Power Supply: Flat cable or drag chain system ensures reliable energy transmission.

• Control Options: Pendant control standard; wireless remote optional for convenience.

• Smart Features: Equipped with hook centering, obstacle prevention, and auto-follow functions.

• Environment: Designed for both indoor and outdoor applications.

Key Advantages

• Exceptional Lifting Capability: Ranges from 1 ton to several tens of tons, with even higher capacities available for specialized tasks.

• Adapted for Demanding Conditions: Operates reliably under high-frequency, heavy-duty workloads.

• Durable and Long-Lasting: Steel wire ropes provide excellent wear resistance, ensuring consistent performance over extended periods.

• Rapid Lifting Performance: Offers faster lifting speeds, particularly advantageous for long-stroke operations.

• Fully Customizable: Design can be tailored to various rail systems and unique operational requirements.

Comparison with Other Cranes

Application Industry

Gantry cranes are widely used across various industries that require safe and efficient handling of heavy loads. Common application areas include:

• Steel and metal processing plants

• Equipment manufacturing workshops

• Heavy machinery assembly lines

• Infrastructure and construction projects

• Warehousing and logistics centers

• Power plants and mining operations

With flexible configuration options and intelligent features, gantry crane system is an ideal solution for projects that demand performance, reliability, and safety.
