10 ton Overhead Crane

Main Components

• Wire Rope Hoist: The primary lifting mechanism that utilizes a drum to spool and unspool the wire rope, facilitating vertical lifting and lowering movements.

• Lifting Rope: Standard synthetic rope for general applications, with an optional high-strength steel wire rope for heavy-duty lifting tasks.

• Trolley: A mobile unit that transports the hoist horizontally along the crane’s girder. Available in both single and double girder configurations.

• Main Girder: The structural beam that provides support for the hoist and trolley. Offered in profile or box girder designs to suit various space and load requirements.

• End Carriages: Contain the wheels that enable the crane to move along its rails, ensuring smooth and stable travel.

• Hooks: Constructed to meet DIN 15401 safety standards, ensuring secure and reliable lifting operations.

• Control System: Controlled via pendant control, remote control, or integrated smart features, offering flexible operation options.

• Electrical System: Includes essential components like motors, wiring, and optional smart technologies such as hook centering and obstacle prevention to improve operational safety and efficiency.

Technical Specifications

• Lifting Capacity: Capable of lifting up to 50 tons.

• Lifting Height: Maximum lifting height of 24 meters.

• Span: Reach up to 30 meters.

• Crane Type: Available in single girder or double girder configurations.

• Girder Design: Choose between profile girder or box girder designs to suit different needs.

• Lifting Rope: Synthetic rope as standard, with the option to upgrade to steel wire rope for heavier lifting tasks.

• Hoisting Motor: 2-speed hoisting motor as standard, with an optional variable frequency drive for smoother control.

• Operating Temperature: Suitable for use in temperatures ranging from +5°C to +40°C.

• Paint Coating: Features a 70 µm epoxy resin powder-coated anodized aluminum frame for enhanced durability.

• Hook Standard: Compliant with DIN 15401 safety standards.

• Trolley Type: Compatible with both single and double girder crane configurations.

• Power Supply: Powered by either flat cable or drag chain systems.

• Control Options: Operate via pendant control or wireless remote control for flexibility.

• Smart Features: Includes advanced features such as hook centering, obstacle prevention, and auto-follow functionality.

• Environment: Ideal for both indoor and outdoor applications.

Key Advantages

• High Lifting Capacity: Typically from 1 ton up to dozens of tons, or even higher for special applications

• Suitable for Complex Working Conditions: Performs reliably under high-frequency and high-intensity operations

• Long Service Life: Steel wire rope offers excellent wear resistance, ideal for long-term continuous use

• Fast Lifting Speed: Ensures higher efficiency, especially beneficial for long lifting strokes

• Highly Customizable: Flexible design options to suit different rail systems and working environments

Comparison with Other Cranes

Application Industry

• Steel and metal processing facilities

• Manufacturing plants for heavy equipment

• Assembly lines for heavy machinery

• Construction and infrastructure development projects

• Warehousing and distribution centers

• Power generation plants and mining operations
