1 Ton Overhead Crane Price

Main Components

• Wire Rope Hoist: The primary lifting mechanism, utilizing a drum to raise and lower loads via the wire rope.

• Lifting Rope: Standard synthetic rope included, with an option for high-strength steel wire rope for heavy-duty applications.

• Trolley: Supports the hoist and moves horizontally along the crane’s girder, suitable for both single and double girder setups.

• Main Girder: The main horizontal beam that holds the trolley and hoist, available in either profile or box girder configurations.

• End Carriages: Contain the wheels that enable the crane to traverse the runway rails smoothly.

• Hooks: Constructed according to DIN 15401 standards to ensure safe and secure lifting.

• Control System: Can be managed through pendant control, remote control, or integrated smart operational features.

• Electrical System: Includes motors, wiring, and optional intelligent functions such as hook centering and obstacle avoidance.

Technical Specifications

• Lifting Capacity: Supports loads up to 50 tons.

• Lifting Height: Maximum vertical reach of 24 meters.

• Span: Can cover distances up to 30 meters.

• Crane Type: Available in Single Girder or Double Girder configurations.

• Girder Design: Options include Profile Girder or Box Girder.

• Lifting Rope: Standard synthetic rope; optional high-strength steel wire rope for heavy-duty lifting.

• Hoisting Motor: 2-Speed motor as standard; Variable Frequency Drive available as an option.

• Operating Temperature: Functional from +5°C to +40°C.

• Paint Coating: 70 µm epoxy resin powder coating applied on anodized aluminum for durability.

• Hook Standard: Manufactured according to DIN 15401 safety standards.

• Trolley Type: Compatible with both Single and Double Girder systems.

• Power Supply: Supports Flat Cable or Drag Chain energy transmission.

• Control Options: Operable via Pendant Control or Wireless Remote Control.

• Smart Features: Includes Hook Centering, Obstacle Prevention, and Auto-Follow functions.

• Environment: Suitable for both Indoor and Outdoor applications.

Key Advantages

• Robust Lifting Capacity: Ranges from 1 ton to multiple tens of tons, with even higher capacities available for specialized applications.

• Reliable in Challenging Conditions: Operates efficiently under high-frequency and heavy-duty work environments.

• Durable for Long-Term Use: Steel wire rope provides excellent resistance to wear, supporting continuous operation over extended periods.

• Efficient Lifting Speed: Delivers fast vertical movement, improving productivity, particularly for long-distance lifts.

• Highly Adaptable Design: Can be customized to fit various rail systems and specific working conditions.

Comparison with Other Cranes

Application Industry

Overhead cranes are widely used across various industries that require safe and efficient handling of heavy loads. Common application areas include:

• Steel & Metal Fabrication Facilities – Ideal for handling, lifting, and transporting heavy steel sheets, beams, and metal components during cutting, welding, and assembly processes.

• Industrial Equipment Manufacturing Workshops – Supports precise movement and placement of machinery parts and equipment during production and assembly.

• Heavy Machinery Assembly Lines – Facilitates efficient lifting, positioning, and installation of large mechanical components in automotive, construction, and industrial machinery lines.

• Infrastructure Development & Construction Sites – Ensures safe handling and transport of construction materials, precast concrete, and structural elements.

• Warehouses and Logistics Hubs – Enhances loading, unloading, and transfer of goods, containers, and heavy pallets in high-throughput storage environments.

• Power Generation Plants and Mining Operations – Enables secure handling of heavy generators, turbines, mining equipment, and industrial machinery in challenging industrial settings.

With flexible configuration options and intelligent features, overhead crane system is an ideal solution for projects that demand performance, reliability, and safety.
